Surface Preparation Machines for Sale

Surface Preparation Machines for Sale
STI's machinery product line includes floor grinding machines, shot blasters, scarifiers, scrapers, dust collectors, swing machines, burnishers, needle scalers, and much more! Substrate Technology - in conjunction with our partners IMPACTS Americas, Airtec, and Von Arx - can competently equip the floor prep and polishing industry with an affordable, diverse selection of high quality machines, diamond systems, tooling, and accessories.
Sort By:
Show:

IMPACTS DC3324 Dust Collector

  • Capacity: 28 gal. (105 liters)
  • Suitable for larger grinding machines or shot blasters
  • Collects fine toxic silica dust to protect operators
  • Available in 230V or 480V
  • All-in-one “lifting lock” for the dust bin handling

IMPACTS DC4025 Dust Collector

  • Capacity: 52 gal. (200 liters)
  • Suitable for larger grinding machines or shot blasters
  • Collects fine toxic silica dust to protect operators
  • All-in-one “lifting lock” for the dust bin handling
  • Can be split into two units

Prep/Master Jr. Floor Grinding Machine

  • Our customers’ favorite little grinder!
  • Heavy head pressure for a better grind and polish – 60% of its weight is on the head!
  • Ideal for residential, garage, and basement projects up to 1,000 SF (100m2)
  • Electric motor: 7.5 HP (5.6kW)
  • Easy disassembly of machine into two sections for easy transportation into hard to reach locations

Prep/Master 2807 Floor Grinding Machine

  • Working width: 28 in. (71cm)
  • For projects up to 2,000 SF (200m2)
  • Electric motor: 7.5 HP (5.5kW)
  • 1 or 3 phase
  • Available in 230V or 480V
  • Use for surface prep and polishing of concrete, terrazzo, and marble

Prep/Master 3003AR Dust Collector

Prep/Master 3003AR Dust Collector

  • Suitable for small to mid-sized machines
  • Uses a Longopac disposal system
  • 300 CFM (510 m3/h)
  • HEPA filter, OSHA-compliant
  • Fully automatic self-cleaning filter cartridges

Prep/Master 2420 Floor Grinding Machine

  • Working width: 24 in. (61cm)
  • For projects up to 5,000 SF (500m2)
  • Electric motor: 20 HP (14.7kW)
  • 1 or 3 phase
  • Available in 230V or 480V
  • Use for surface prep and polishing of concrete, terrazzo, and marble

Prep/Master 3030 Floor Grinding Machine

  • Our most popular model!
  • Working width: 30 in. (76 cm)
  • For projects up to 10,000 SF (1,000m2)
  • Electric motor: 30 HP (22kW); 1 or 3 phase
  • Available in 230V or 480V
  • Use for surface prep and polishing of concrete, terrazzo, and marble

Vacuum Wand & Floor Tool

  • Sturdy metal materials
  • Vacuum Wand: 48-in. long, 2-in. diameter, single bend, chrome body
  • Floor Tool with rollers: 18-inch width
  • Gap between floor tool and floor surface is adjustable
  • Brushes and squeegees are replaceable
  • Items purchased separately (must purchase both parts to get full wand package)
  • Various adapters and reducers for 2″ and 3″ hoses (sold separately)


When it comes to surface preparation machines, Substrate Technology has all you need. Everything from small jobs to large projects can be done with our variety of surface preparation equipment machines, including:

Using the right machine makes every surface prep job easier, safer, and more effective. We want you and your crew to have the perfect surface preparation machine for every job.

Dust Collectors

Dust removal improves safety, cleanliness, and quality. Power tools, especially in surface prep, create lots of dust from surface grinding and polishing. Whatever the project, a smart contractor plans their dust collection to prolong the life of their tools and protect their workers. We offer several dust collectors suitable for any sized project.

Floor Grinding Machines

A floor grinder can stop you from having to replace a floor. You can level uneven surfaces, smooth over cracks, remove unwanted coatings and create a polishing effect. All these possibilities mean you can repair most issues with a surface. Floor grinding machines are versatile and efficient.

If you are working on a small area, an electric floor grinder works well. The need for a power outlet means the range of movement can be limited. For indoor use, there is little need for ventilation when using.

Propane powered floor grinders make quick work of larger areas. You just need to keep the tank filled up. Be aware of the need for ventilation though, as the fumes can be harmful. You will also need noise protection.

Scarifiers

Scarifiers are like floor grinders but are for more heavy-duty tasks. They will quickly remove the top layer of a concrete surface with their cutting wheels. This means you can lay a new surface down quickly. If the concrete is very uneven, it is best to use a scarifier. They can also be used to add a non-slip texture to walkways, meaning less chance of accidents. Facilities showing traffic lines can use a scarifier to remove these as well.

Shot Blasters

The process with a shot blaster is how it sounds. They fire steel pellets into the surface. The relentless pressure of this chips away imperfections and will give the surface the desired effect. No matter the size of the job, there are models available. These range from small handheld models up to ride-on shot blasters for vast areas.

Swing Machines

Some people call these Rotary Floor Machines. They can help restore the shine to any dull surface. They have powerful motors and a variety of pad options. If you attach the right pads, they will be much more effective than brushing and mopping. They can remove embedded dirt and buff away an assortment of scratches and other surface damage.

Vacuums

A lot of debris will build up in surface preparation jobs. Use a vacuum specifically designed for concrete. This way you can remove it without jamming the machine. Concrete dust contains silica, which can cause fatal lung diseases. Sweeping will create more dust than it removes, so it is not the best option. Our concrete vacuums are designed with durability in mind. After all, we use them on construction sites and industrial environments. Our durable machines can suck up the worst and keep coming back for more.

Order Your Surface Prepartion Machines Today

At Substrate Technology, Inc., we have everything you need for professional concrete, stone, and terrazzo surface preparation. To get a free quote on the equipment and materials you need or to learn more about our selection, please call   +1 (815) 941-4800 or complete our contact form.
